The secret of C.O.R.E. is out, with a spectacular unveiling show at EMO 2021.
Learn more about C.O.R.E. and what role it plays in the digital future of your production here.
The following products will be presented
In its basic version this sturdy grinding center comes with an integrated tool changer in a gantry design with 68 positions.
PLANOMAT XT Essential
The competitive 3 axis entry level machine for high precision surface and profile grinding
Higher main axis speeds, greater acceleration and increased system rigidity - the combination of these consistently optimized essential performance characteristics means increased productivity while improving component quality.
The favoritCNC is a universal cylindrical grinding machine for medium-sized workpieces. It has distances between centres of 650mm (25.6") / 1000mm (40") and a centre height of 175mm (6.8"). It can machine workpieces with a maximum weight of 80kg (176lbs) / 120kg (264lbs).
The S31 is a cylindrical grinding machine for small to large workpieces It has a distance between centres of 400mm (15.7") / 650mm (25.6") / 1,000mm (40") / 1,600mm (63") and a centre height of 175mm (6.9"). It can machine workpieces with a maximum weight of 150kg (330lbs).
The S41 is a CNC universal cylindrical grinding machine for large workpieces. It has distances between centres of 1000mm (40") / 1600mm (63") and centre heights of 225mm (8.8") / 275mm (10.8"). It can machine workpieces with a maximum weight of 250kg (550lbs).
The S131 is a radius internal cylindrical grinding machine that is especially suitable for grinding complex workpieces from very hard materials The maximum swing diameter is 300mm (11.7") and the maximum workpiece weight is 100kg (220lbs).
The high-end HELITRONIC MICRO tool grinding machine produces and sharpens rotationally symmetrical tools and production parts with smaller diameters.
HELITRONIC VISION 400 L
The high-end HELITRONIC VISION 400 L tool grinding machine stands for the highest accuracy and dynamics in volume production for tool lengths up to 420 mm.
HELICHECK PLUS is the universally used measuring machine for both micro-tools and tools in the standard range. Measurements for transmitted light and incident light are performed by the HELICHECK PLUS operator-independent, CNC-controlled and μ-precise.
LASER LINE PRECISION
The LASER LINE PRECISION laser processing machine handles ultra-hard materials such as PCD, CVD-D, CBN and MKD by laser. It can accommodate rotation-symmetric tools of up to 200 mm in diameter and up to 250 mm in length and indexable inserts from 3 mm internal and up to 50 mm external diameter.
